| Type | RQM-QBXF-5500 |
| Wire range | φ0.3-φ0.7mm |
| No. of line | 24 - 36 |
| No. Of passes perline | 9 – 13 |
| Wire pitch | 6.0 - 7.0 mm |
| Mechanical speed | Max: 130 m/min |
| Self-bonding oven | Hot air circulation and exchange type |
| Length of the oven | 5500 mm |
| Length of softening oven | 9000~12000 mm |
| Suitable pay off spool | φ400-φ500 |
| Take up method | Torque type axes winding unit |
| Suitable take-up spool | PT10-PT60; PT25-PT270 |
| Namel application method | Felt/Die,inverter control of enamel quantity |
| Application method | Automatic liquid level adjustment paint box |
| Threading method | One belt with two wires |
| Steam generator | Hot exhaust gas is adopted |
| Exhaust gas dispose | Two catalysts burning system |
| Installed electric power | About 155 KW |
|
Specs （mm） |
| φ0.3 |
| φ0.4 |
| φ0.5 |
| φ0.6 |
| φ0.7 |
| DV | Production speed(m/min) | Daily output(kg/24h) |
Daily power consumption Kwh/24h (felt painting) |
|||
| PE | PU | PE | PU | PE | PU | |
| 27~33 | 32~35 | 90~110 | 106.7~116 | 2592~3168 | 3072~3360 |
Production φ 0.5 wire diameter copper wire about 700 degrees |
| 27~32 | 31~34 | 67.5~80 | 77.5~85 | 3456~4096 | 3968~4352 | |
| 27~31 | 30~33 | 54~62 | 60~66 | 4320~4960 | 4800~5280 | |
| 27~30 | 29~32 | 45~50 | 48.3~53.3 | 5184~5760 | 5568~6144 | |
| 25~29 | 27~31 | 35.7~41.5 | 38.5~44.2 | 5600~6014 | 6048~6944 | |
